Swappable Alpha unit sample blocks are designed for frequent change; they can be swapped in seconds; they seat many types of reaction vessels.

Independently controlled dual blocks are available for running two different protocols simultaneously.

Gradient Capability is standard on all DNA Engine systems when fitted with 96-well Alpha units.

Unique Peltier heat pumps are built by MJ Research specifically for cycling.   Years of experience and proprietary technologies make MJ modules last longer than any other.

Multi-zone feedback control utilizes multiple sensors combined with four “zones” for heating and/or cooling to optimize thermal profiles every 50 milliseconds.

Performance

Extraordinary temperature uniformity of ±0.4°C within 30 seconds of arrival at 90°C (well-to-well) average, all Alphas).

Superb thermal accuracy of blocks within ±0.3°C of NIST standard at 90°C (average across block, all Alphas).

Thermal range of -5° to 105°C

Rapid ramp rates of up to 3.0°C/sec

Operation

Two thermal control options block control or calculated control.

Choice of two heated-lid designs accommodate many vessel types and various sealing options, allowing maximum flexibility in experimental designs.   Heated lid temperatures can be set with any DNA Engine instrument.


Manual Hot Bonnet^® heated lid with a unique thumbwheel for adjusting height and pressure
Moto Alpha™ units can be remotely commanded to open, close, and adjust height and pressure.   Alternatively it may be opened and closed with the touch of a button.
